Specification
| Model | PPKP-10 | ||
| Heating Capacity Range | kW | 2-10 | |
| Heating (A7/6℃,W30/35℃) |
Heating Capacity | kW | 9.9 |
| Power Input | kW | 2.28 | |
| COP | W/W | 4.35 | |
| Heating (A-12℃,W36/41℃) |
Heating Capacity | kW | 6.93 |
| Power Input | kW | 2.83 | |
| COP | W/W | 2.45 | |
| Heating (A7/6℃,W40/45℃) |
Heating Capacity | kW | 9.5 |
| Power Input | kW | 2.75 | |
| COP | W/W | 3.45 | |
| Heating (A7/6℃,W47/55℃) |
Heating Capacity | kW | 7.27 |
| Power Input | kW | 2.55 | |
| COP | W/W | 2.85 | |
| Cooling (A35/24℃,W23/18℃) |
Cooling Capacity | kW | 8.99 |
| Power Input | kW | 2.41 | |
| EER | W/W | 3.73 | |
| Cooling A35/24℃,W12/7℃) | Cooling Capacity | kW | 8.1 |
| Power Input | kW | 2.03 | |
| EER | W/W | 2.93 | |
| Maximum input power | kW | 3.1 | |
| High Pressure Value Cut-off Pressure | MPa | 4.2Mpa | |
| Low Pressure Valve Cut-off Pressure | MPa | 0.05Mpa | |
| Brand/Type of Compressor | / | panasonic | |
| Brand of EEV | EEV | SANHUA | |
| Brand Of 4-way Valve | SANHUA | ||
| Brand Of Water Pump | WILO | ||
| Waterproof Grade | I | IPX4 | |
| Noise Pressure | dB(A) | 46 | |
| Max Water Outlet Ternperature | °C | 55 | |
| Diameter Of Water Connection | / | DN 25 (1") | |
| Drainage Valve | mm | / | |
| Lowest Operationa I point, outdoor air/flow line (heating mode ) |
-25 | ||
| Highest Operationa I point, outdoor air/flow line (heating mode ) |
43 | ||
| Package Dimensions ( L/W/H ) | mm | 1120*490*990 | |
| Gross Weight | KG | 108 | |
