Specification
| Model | PPKP-18 | ||
| Heating Capacity Range | kW | 6-20 | |
| Heating (A7/6℃,W30/35℃) |
Heating Capacity | kW | 18.5 |
| Power Input | kW | 4.32 | |
| COP | W/W | 4.28 | |
| Heating (A-12℃,W36/41℃) |
Heating Capacity | kW | 12.8 |
| Power Input | kW | 4.89 | |
| COP | W/W | 2.62 | |
| Heating (A7/6℃,W40/45℃) |
Heating Capacity | kW | 18.21 |
| Power Input | kW | 5.1 | |
| COP | W/W | 3.57 | |
| Heating (A7/6℃,W47/55℃) |
Heating Capacity | kW | 16.42 |
| Power Input | kW | 5.43 | |
| COP | W/W | 3.02 | |
| Cooling (A35/24℃,W23/18℃) |
Cooling Capacity | kW | 17.82 |
| Power Input | kW | 4.92 | |
| EER | W/W | 3.62 | |
| Cooling A35/24℃,W12/7℃) | Cooling Capacity | kW | 14.5 |
| Power Input | kW | 4.79 | |
| EER | W/W | 2.82 | |
| Maximum input power | kW | 6.74 | |
| High Pressure Value Cut-off Pressure | MPa | 4.2Mpa | |
| Low Pressure Valve Cut-off Pressure | MPa | 0.05Mpa | |
| Brand/Type of Compressor | / | panasonic | |
| Brand of EEV | EEV | SANHUA | |
| Brand Of 4-way Valve | SANHUA | ||
| Brand Of Water Pump | WILO | ||
| Waterproof Grade | I | IPX4 | |
| Noise Pressure | dB(A) | 52 | |
| Max Water Outlet Ternperature | °C | 55 | |
| Diameter Of Water Connection | / | DN 25 (1") | |
| Drainage Valve | mm | / | |
| Lowest Operationa I point, outdoor air/flow line (heating mode ) |
-25 | ||
| Highest Operationa I point, outdoor air/flow line (heating mode ) |
43 | ||
| Package Dimensions ( L/W/H ) | mm | 1120*490*1500 | |
| Gross Weight | KG | 165 | |
