Specification
| Model | |||
| Voltage | Volts | 230/208 | |
| Cooling capacity | Nominal | W (BTU/hr) | 3517 (12000) |
| Min. – max. | W (BTU/hr) | 700–3710 (2380–13307) | |
| Used rated input | W | 1650 | |
| Rated current | A | 6.7 | |
| SEER2(SEER) | - | 17.5 (17.5) | |
| HSPF2(HSPF) | - | 8.5 (10) | |
| EER | W/W | 2.64 | |
| COP | W/W | 3.50 | |
| Indoor Unit | |||
| Dehumidification | pt/hr(l/hr) | 2.86 (1.40) | |
| Air flow volume | cfm | 424 / 353 / 324 / 277 / 247 / 224 / 192 | |
| Sound level | dB (A) | / 57 / 49 / 48 / 45 / 43 / 42 / 37 | |
| Fan motor power output | W | 15 | |
| Fan motor RLA | A | 0.40 | |
| Deflector stepper motor power output | W | 1.5 | |
| Net weight | lb (kg) | 19.8 (9) | |
| Outdoor Unit | |||
| Air flow volume | m³/hr | 1950 | |
| Sound level | dB (A) | 52 | |
| Compressor power input | W | 857 | |
| Refrigerant volume (R410A) | oz (g) | 27.5 (750) | |
| Net weight | lb (kg) | 57.33 (26) | |
| Operating ambient temperature | Cooling | °C (°F) | -18 to 46 (0 to 115) |
| Heating | °C (°F) | -25 to 24 (-4 to 75) | |
