Specification
| Model | |||
| Voltage | Volts | 230/208 | |
| Cooling capacity | Nominal | W (BTU/hr) | 5159 (17600) |
| Min. – max. | W (BTU/hr) | 1100–5850 (3753–19960) | |
| Used rated input | W | 2300 | |
| Rated current | A | 9.5 | |
| SEER2(SEER) | - | 17.5 (17.5) | |
| HSPF2(HSPF) | - | 8.5 (9) | |
| EER | W/W | 2.95 | |
| COP | W/W | 3.20 | |
| Indoor Unit | |||
| Dehumidification | pt/hr(l/hr) | 3.8 (1.80) | |
| Air flow volume | cfm | 618 / 542 / 471 / 436 / /395 / 336 / 283 | |
| Sound level | dB (A) | 60 / 58 / 54 / 52 / 50 / 46 / 45 | |
| Fan motor power output | W | 45 | |
| Fan motor RLA | A | 0.70 | |
| Deflector stepper motor power output | W | 2.5 | |
| Net weight | lb (kg) | 28.7 (13) | |
| Outdoor Unit | |||
| Air flow volume | m³/hr | 2520 | |
| Sound level | dB (A) | 57 | |
| Compressor power input | W | 1295 | |
| Refrigerant volume (R410A) | oz (g) | 44.1 (1150) | |
| Net weight | lb (kg) | 71.70 (32.5) | |
| Operating ambient temperature | Cooling | °C (°F) | -18 to 46 (0 to 115) |
| Heating | °C (°F) | -25 to 24 (-4 to 75) | |
