Specification
| Model | |||
| Voltage | Volts | 230/208 | |
| Cooling capacity | Nominal | W (BTU/hr) | 6450 (22000) |
| Min. – max. | W (BTU/hr) | 2000–7400 (6824–25249) | |
| Used rated input | W | 2400 | |
| Rated current | A | 12 | |
| SEER2(SEER) | - | 18 (18) | |
| HSPF2(HSPF) | - | 8.5 (10) | |
| EER | W/W | 3.40 | |
| COP | W/W | 3.43 | |
| Indoor Unit | |||
| Dehumidification | pt/hr(l/hr) | 5.29 (2.50) | |
| Air flow volume | cfm | 677 / 598 / 559 / 506 / 471 / 441 / 412 | |
| Sound level | dB (A) | 61 / 57 / 55 / 52 /50 / 48 / 46 | |
| Fan motor power output | W | 60 | |
| Fan motor RLA | A | 0.45 | |
| Deflector stepper motor power output | W | 2.5 | |
| Net weight | lb (kg) | 33 (18) | |
| Outdoor Unit | |||
| Air flow volume | m³/hr | 3200 | |
| Sound level | dB (A) | 57 | |
| Compressor power input | W | 1330 | |
| Refrigerant volume (R410A) | oz (g) | 52.9 (1500) | |
| Net weight | lb (kg) | 97 (44) | |
| Operating ambient temperature | Cooling | °C (°F) | -18 to 46 (0 to 115) |
| Heating | °C (°F) | -25 to 24 (-4 to 75) | |
