Specification
| Model | 24000BTU | ||
| Type | heating pump | ||
| Control type | remote | ||
| Rated cooling capacity | Btu/h;W | 24000(5120~24900) | |
| Rated heating capacity | Btu/h;W | 24000(5120~24900) | |
| EER for cooling | W/W | 2.81 | |
| COP for heating | W/W | 2.81 | |
| Moisture removal | Liters/h | 2.2 | |
| Pressure | High(DP) | MPa | 4.5 |
| Low(SP) | MPa | 1.9 | |
| Indoor noise level(S/H/M/L/Mute) | dB(A) | 49/47/45/43/41 | |
| Outdoor noise level | dB(A) | 55 | |
| Electrical Data | |||
| Power supply | 220-240V~/50-60Hz/1P | ||
| Voltage Range | V | 198~242 | |
| Rated current | Cooling | A | 11.8(1.5~13.5) |
| Heating | A | 11.8(1.5~13.0) | |
| Rated input | Cooling | W | 2500(350~2800) |
| Heating | W | 2500(350~2700) | |
| Annual energy consumption(cooling) | kwh | 1250 | |
| Max Current | Cooling | A | 13.5 |
| Heating | A | 13.0 | |
| Max Power input | Cooling | W | 2800 |
| Heating | W | 2700 | |
| Refrigerating&Fan System | |||
| Refrigerant | R32/R410A | ||
| Compressor | Type | Rotary | |
| Model | C-6RZ146H3DBF | ||
| Brand | SANYO | ||
| Expansion device | Capillary tube | ||
| Indoor air circulation(Cooling/Heating) | m3/h | 1300/1300 | |
| Connections | |||
| Connecting Pipe | Gas | mm | Φ12(1/2'') |
| Liquid | mm | Φ6(1/4'') | |
| Connecting Wiring | Size x Core number | 3×1.5;4×0.75 | |
| Suitable area | m2 | 30~50 | |
| Max. refrigerant pipe length | m | 15 | |
| Max. difference in level | m | 5 | |
| Operation temperature range | ℃ | 16~31 | |
| Ambient temperature range | Outdoor | ℃ | Cooling:15-43/Heating:-7-24 |
| Indoor | ℃ | Cooling:17-32/Heating:0-27 | |
| Net dimensions (W x D x H) |
Indoor | mm | 1010x315x220 |
| Outdoor | mm | 853×349×602 | |
| Net weight | Indoor | kg | 13 |
| Outdoor | kg | 32 | |
| Packing dimensions (W x D x H) |
Indoor | mm | 1096×390×297 |
| Outdoor(w/o pipe) | mm | 890×385×628 | |
| Gross weight | Indoor | kg | 16 |
| Outdoor(w/i pipe) | kg | 35 | |
| Loading Capacity w/i pipe | 20'/40'GP/40'HQ | 200 | |
