Store » Central Air Conditioner » VRF System » VRF System 33.5kW
Puremind inverter ceiling HVAC cassette

VRF System 33.5kW

  • Free match with fan coil indoor unit
  • Capability of heating and cooling
  • Full DC inverter technologies
  • Intelligent temperature control technology
  • Centralized control
  • Small installation space and quiet operation
  • Ultra-long connection pipe
SKU: PGKV-33.5 Categories: , , Tags: , , , , , ,
WhatsAppGet Quote
variable flow mini VRF unit for light commercial
smart control mini VRF aircon
compact VRF inverter unit with fan motor
ceiling-mounted inverter cassette AC
Puremind embedded cassette type AC
low noise ceiling cassette air conditioner
smart cassette AC with remote control
Puremind ducted split VRF cooling unit
Puremind inverter cassette air conditioner unit
floor-standing mini VRF AC cabinet
heat recovery mini VRF cooling and heating unit
Puremind outdoor compact VRF aircon
high-efficiency mini VRF with golden fin coil
Puremind ductless VRF air conditioning unit

Specification

Model PGKV-33.5
Capacity Range HP 12
Capacity Cooling kW 33.5
Heating kW 37.5
EER W/W 4.35
COP W/W 4.81
Power Supply V/Ph/Hz 380-415V 3N~50/60Hz
Min. circuit/Max. fuse Current A 24.1/25
Power Consumption Cooling kW 7.70
Heating kW 7.80
Maximum Drive IDU NO. unit 19
Refrigerant Charge Volume kg 5.7
Sound Pressure Level dB(A) 59
Connecting Pipe Liquid mm φ12.7
Gas mm φ25.4
Dimension (WxDxH) Outline mm 930*775*1690
Package mm 1000*830*1855
Net Weight/Gross Weight kg 220/230
Loading Quantity 40'GP unit 28
40'HQ unit 28

[elementor-template id="19255"]

Introduction

The Puremind VRF System 33.5kW delivers superior cooling performance for expansive commercial and industrial spaces. Designed with advanced VRF technology, this system ensures energy efficiency, precise climate control, and seamless integration into modern HVAC systems.

Key Features of Puremind VRF System 33.5kW

Superior Cooling Power
With a cooling capacity of 33.5kW, this system is perfect for large-scale applications, including office buildings, industrial facilities, and retail spaces.
Energy-Saving Technology
Advanced VRF technology minimizes energy consumption, reducing operational costs while maintaining optimal performance.
Customizable Options
Fully customizable through our OEM/ODM services, enabling tailored solutions for unique project needs.
Quiet and Efficient Operation
Engineered for low noise levels and maximum efficiency, providing a comfortable environment without disruptions.
Smart Climate Control
Integrated with IoT-enabled controls for remote management and real-time performance monitoring.

Applications of Puremind VRF System 33.5kW

This VRF system is tailored
Corporate Offices
Efficient cooling for multi-level office buildings.
Industrial Settings
Designed for factories, logistics hubs, and large-scale production facilities.
Educational Institutions
Quiet operation for classrooms, libraries, and lecture halls.
Retail Spaces
Maintains a comfortable shopping experience in malls and large stores.
Hospitality
Ensures premium comfort in hotels, resorts, and conference venues.

Why Choose Puremind VRF System 33.5kW

OEM/ODM Expertise
Collaborate with our expert team to design VRF systems that align with your project’s unique requirements.
Global Standards
All products are manufactured to meet international quality and safety standards, ensuring reliable performance.
Sustainability Focus
Incorporates energy-efficient technologies to minimize environmental impact.
